Image STM8S003F3P6
型号: STM8S003F3P6
厂商: STMicroelectronics STMicroelectronics
标准:
分类: 半导体集成电路 - IC
描述: 8-bit microcontrollers - mcu 8-bit mcu value line 16 mhz 8kb FL 128ee
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

STM8S003F3P6的详细信息

Manufacturer: STMicroelectronics
Product Category: 8-bit Microcontrollers - MCU
RoHS: Yes
A/D Bit Size: 10 bit
Core: STM8
Data Bus Width: 8 bit
Maximum Clock Frequency: 16 MHz
Program Memory Size: 8 kB
Data RAM Size: 1 kB
On-Chip ADC: Yes
Operating Supply Voltage: 2.95 V to 5.5 V
Maximum Operating Temperature: + 85 C
Package / Case: TSSOP-20
Mounting Style: SMD/SMT
A/D Channels Available: 5
Brand: STMicroelectronics
Data RAM Type: RAM
Data ROM Size: 128 B
Data ROM Type: EEPROM
Interface Type: I2C, SPI, UART
Minimum Operating Temperature: - 40 C
Number of Timers: 3
On-Chip DAC: No
Packaging: Tube
Processor Series: STM8S
Program Memory Type: Flash
Series: STM8S003F3
Factory Pack Quantity: 74
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.95 V
STM8S003K3 STM8S003F3
Value line, 16 MHz STM8S 8-bit MCU, 8 Kbytes Flash, 128 bytes
data EEPROM, 10-bit ADC, 3 timers, UART, SPI, I²C
Interrupt management
Nested interrupt controller with 32 interrupts
Up to 27 external interrupts on 6 vectors
Timers
Advanced control timer: 16-bit, 4 CAPCOM
channels, 3 complementary outputs, dead-time
insertion and flexible synchronization
TSSOP20
LQFP32 7x7
UFQFPN20 3x3
16-bit general purpose timer, with 3 CAPCOM
channels (IC, OC or PWM)
8-bit basic timer with 8-bit prescaler
Auto wake-up timer
Features
Core
Window watchdog and independent watchdog
timers
16 MHz advanced STM8 core with Harvard
architecture and 3-stage pipeline
Communications interfaces
Extended instruction set
UART with clock output for synchronous
operation, Smartcard, IrDA, LIN master mode
Memories
SPI interface up to 8 Mbit/s
I2C interface up to 400 Kbit/s
Program memory: 8 Kbytes Flash; data retention
20 years at 55 °C after 100 cycles
RAM: 1 Kbytes
Data memory: 128 bytes of true data EEPROM;
endurance up to 100 000 write/erase cycles
Analog to digital converter (ADC)
10-bit, ±1 LSB ADC with up to 5 multiplexed
channels, scan mode and analog watchdog
Clock, reset and supply management
I/Os
2.95 to 5.5 V operating voltage
Up to 28 I/Os on a 32-pin package including 21
high sink outputs
Flexible clock control, 4 master clock sources:
Low power crystal resonator oscillator
-
Highly robust I/O design, immune against current
injection
External clock input
-
Internal, user-trimmable 16 MHz RC
-
Development support
Internal low power 128 kHz RC
-
Embedded single wire interface module (SWIM)
for fast on-chip programming and non intrusive
debugging
Clock security system with clock monitor
Power management:
Low power modes (wait, active-halt, halt)
-
Switch-off peripheral clocks individually
-
Permanently active, low consumption power-on
and power-down reset
June 2012
1/100
DocID018576 Rev 3
www.st.com
