型号: TLP250(F)
厂商: Toshiba
标准:
分类: 半导体集成电路 - IC
描述: logic output optocouplers 2500vrms 0.15 high speed
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 第三方平台下载 >>

TLP250(F)的详细信息

Manufacturer: Toshiba
Product Category: Logic Output Optocouplers
RoHS: Yes
Brand: Toshiba
Isolation Voltage: 5000 Vrms
Output Type: Bipolar
Maximum Forward Diode Voltage: 1.8 V
Maximum Reverse Diode Voltage: 5 V
Maximum Forward Diode Current: 20 mA
Maximum Continuous Output Current: 1.5 A
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
Package / Case: DIP-8
Packaging: Bulk
Number of Channels per Chip: 1 Channel
Factory Pack Quantity: 50
TLP250F
TOSHIBA Photocoupler GaAAs IRed & Photo-IC
TLP250F
Transistor Inverter
Unit in mm
Inverter for Air Conditionor
IGBT Gate Drive
Power MOSFET Gate Drive
The TOSHIBA TLP250F consists of a GaAAs light emitting diode and
an integrated photodetector.
This unit is 8lead DIP.
TLP250F is suitable for gate driving circuit of IGBT or power MOSFET.
Input threshold current: I = 5mA (max.)
F
Supply current: 11mA (max.)
Supply voltage: 10~35V
Output current: ±1.5A (max.)
Switching time: t
, t
= 0.5μs (max.)
pHL pLH
Isolation voltage: 2500 V
(min.)
rms
UL recognized: UL1577, file no. E67349
Option (D4) type
TOSHIBA
1110C402
VDE approved: DIN EN 60747-5-2, certificate No. 40011913
Maximum operating insulation voltage: 1140V
PK
Weight: 0.54 g (typ.)
Highest permissible over voltage: 6000V
PK
(Note 1) When a EN 60747-5-2 approved type is needed,
please designate the “ Option (D4) ”
Structural parameter
Creepage distance: 8.0mm (min.)
Clearance: 8.0mm (min.)
Truth Table
Tr1
Tr2
On
Off
On
Off
Off
On
Input
LED
1
