型号: UA741CP
厂商: Texas Instruments Texas Instruments
标准:
分类: 半导体集成电路 - IC
描述: operational amplifiers - Op amps GP Op amp
PDF: 预览
报错 收藏

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

UA741CP的详细信息

Manufacturer: Texas Instruments
Product Category: Operational Amplifiers - Op Amps
RoHS: Yes
Amplifier Type: General Purpose Amplifier
Gain Bandwidth Product: 1 MHz
Number of Channels: 1 Channel
Common Mode Rejection Ratio - Min: 70 dB
Input Offset Voltage: 6 mV
Input Bias Current - Max: 500 nA
Operating Supply Voltage: +/- 3.5 V to +/- 18 V
Mounting Style: Through Hole
Package / Case: PDIP-8
Slew Rate: 0.5 V/us
Shutdown: No Shutdown
Maximum Operating Temperature: + 70 C
Packaging: Tube
Brand: Texas Instruments
Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
Maximum Dual Supply Voltage: +/- 18 V
Minimum Dual Supply Voltage: +/- 3.5 V
Minimum Operating Temperature: 0 C
Series: UA741
Factory Pack Quantity: 50
Supply Current: 2.8 mA
Technology: Bipolar
Unit Weight: 440.400 mg
SLOS094D NOVEMBER 1970REVISED FEBRUARY 2014
µA741x General-Purpose Operational Amplifiers
1 Features
2 Description
The µA741 device is a general-purpose operational
amplifier featuring offset-voltage null capability.
1
Short-Circuit Protection
Offset-Voltage Null Capability
The high common-mode input voltage range and the
absence of latch-up make the amplifier ideal for
voltage-follower applications. The device is short-
circuit protected and the internal frequency
compensation ensures stability without external
components. A low value potentiometer may be
connected between the offset null inputs to null out
the offset voltage as shown in Figure 2.
Large Common-Mode and Differential Voltage
Ranges
No Frequency Compensation Required
No Latch-Up
Designed to Be Interchangeable With Fairchild
µA741
The µA741C device is characterized for operation
from 0°C to 70°C. The µA741M device (obsolete) is
characterized for operation over the full military
temperature range of –55°C to 125°C.
µA741M . . . J PACKAGE
(TOP VIEW)
µA741M . . . JG PACKAGE
µA741C, µA741I . . . D, P, OR PW PACKAGE
(TOP VIEW)
NC
NC
NC
NC
NC
V
1
2
3
4
5
6
7
14
13
12
11
10
9
OFFSET N1
IN–
NC
V
1
2
3
4
8
7
6
5
OFFSET N1
IN–
CC+
IN+
OUT
CC+
V
OFFSET N2
IN+
CC–
OUT
V
OFFSET N2
NC
CC
NC
8
µA741M . . . FK PACKAGE
(TOP VIEW)
µA741M . . . U PACKAGE
(TOP VIEW)
NC
NC
NC
V
1
2
3
4
5
10
9
OFFSET N1
IN–
8
CC+
IN+
OUT
7
V
OFFSET N2
6
CC–
3
2
1
20 19
18
NC
V
NC
IN–
NC
4
5
6
7
8
17
16
15
14
CC+
NC
OUT
NC
IN+
NC
9 10 11 12 13
NC – No internal connection
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
