Molex
0393570024的详细信息
| Datasheets： | |
|---|---|
| 0393570024 Drawing： | |
| RoHS Information： | |
| 393570024 Cert of Compliance： | |
| 3D Model： | |
| 39357-0024.stp： | |
| Standard Package ： | 50 |
| Category： | Connectors, Interconnects |
| Family： | Terminal Blocks - Wire to Board |
| Series： | Eurostyle™ 39357 |
| Packaging ： | Bulk |
| Number of Levels： | 1 |
| Positions Per Level： | 24 |
| Pitch： | 0.138" (3.50mm) |
| Mating Orientation： | Horizontal with Board |
| Current： | 12A |
| Voltage： | 300V |
| Wire Gauge： | 16-28 AWG |
| Mounting Type： | Through Hole |
| Wire Termination： | Screw - Rising Cage Clamp |
| Features： | - |
| Color： | Black |
| Operating Temperature： | -40°C ~ 105°C |
| Housing Material： | Polyamide (PA), Nylon |
| Contact Material - Plating： | Copper Alloy - Tin Plated |
| Clamp Material - Plating： | Copper Alloy - Nickel Plated |
| Screw Material - Plating： | Copper Alloy - Nickel Plated |
| Torque - Screw： | 0.31 Nm (2.7 Lb-In) |
| Screw Thread： | M3 |
| Other Names： | 0393-57-0024039357-0024393-57-002439357-0024393570024 |
