Molex
0459714417的详细信息
| Datasheets： | |
|---|---|
| 0459714417： | |
| SEARAY&trade： | |
| Product Spec： | |
| Intermateability Prod Spec： | |
| SEARAY&trade： | |
| Test Summary： | |
| SEARAY&trade： | |
| IPC-9701A Test Summary： | |
| SEARAY&trade： | |
| Appl Spec： | |
| SEARAY&trade： | |
| Connector Routing Guide： | |
| RoHS Information： | |
| 0459714417 Cert of Compliance： | |
| 3D Model： | |
| 45971-4417.stp： | |
| 45971-4417.igs： | |
| 45971-4417.prt： | |
| Standard Package ： | 230 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
| Series： | SEARAY™ 45971 |
| Packaging ： | Tape & Reel (TR) |
| Connector Type： | High Density Array, Female |
| Number of Positions： | 400 |
| Pitch： | 0.050" (1.27mm) |
| Number of Rows： | 10 |
| Mounting Type： | Surface Mount |
| Features： | Board Guide |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 30µin (0.76µm) |
| Mated Stacking Heights： | 9.5mm, 10mm, 10.5mm, 11mm, 12mm, 12.5mm, 14.5mm |
| Height Above Board： | 0.295" (7.50mm) |
| Mating Products： | 0459704311-ND - PLUG 10ROW 400POS VERT BRD-BRD0459704215-ND - PLUG 10ROW 400POS VERT BRD-BRD |
| Other Names： | 045971-441745971-4417459714417 |
