Molex
0717410002的详细信息
| Datasheets： | |
|---|---|
| 0717410002： | |
| Mezzanine 1mm Pkg Specs： | |
| 71741, 71742 Series Specs： | |
| Product Photos： | |
| 0717410002： | |
| RoHS Information： | |
| 0717410002 Cert of Compliance： | |
| 3D Model： | |
| 71741-0002.stp： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
| Series： | Mezzanine 71741 |
| Packaging ： | Cut Tape (CT) |
| Connector Type： | Plug, Center Strip Contacts |
| Number of Positions： | 84 |
| Pitch： | 0.039" (1.00mm) |
| Number of Rows： | 2 |
| Mounting Type： | Surface Mount |
| Features： | Board Guide |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 10µin (0.25µm) |
| Mated Stacking Heights： | 10mm, 12mm, 15mm |
| Height Above Board： | 0.327" (8.30mm) |
| Dynamic Catalog： | Mezzanine Series |
| Mating Products： | WM3499CT-ND - MEZZANINE 1MM BTB RECPT 84CKTWM3499DKR-ND - MEZZANINE 1MM BTB RECPT 84CKTWM3499TR-ND - MEZZANINE 1MM BTB RECPT 84CKT |
| Other Names： | WM3498CT |
