Molex
0857290101的详细信息
| Datasheets： | |
|---|---|
| 857290101 Drawing： | |
| PCN Assembly/Origin： | |
| Multiple Series 02/Jun/2014： | |
| Standard Package ： | 48 |
| Category： | Connectors, Interconnects |
| Family： | Modular Connectors - Jacks With Magnetics |
| Series： | 85729 |
| Packaging ： | Tray |
| Connector Type： | RJ45 |
| Number of Ports： | 8 |
| Number of Rows： | 2 |
| Applications： | 10/100/1000 Base-T, AutoMDIX, Power over Ethernet+ (PoE+) |
| Mounting Type： | Through Hole |
| Orientation： | 90° Angle (Right) |
| Termination： | Solder |
| Height Above Board： | 1.002" (25.46mm) |
| LED Color： | Does Not Contain LED |
| Number of Cores per Jack： | - |
| Shielding： | Shielded, EMI Finger |
| Features： | Board Guide |
| Tab Direction： | Up and Down |
| Contact Material： | Copper Alloy |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 30µin (0.76µm) |
| Shield Material： | Brass |
| Housing Material： | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Operating Temperature： | 0°C ~ 70°C |
| Other Names： | 0857-29-0101857-29-010185729-0101857290101 |
