| Datasheets： |
|
| 331366： |
|
| RoHS Information： |
|
| 1-331366-0 Statement of Compliance： |
|
| RoHS 2 Statement： |
|
| Standard Package ： |
10,000 |
| Category： |
Connectors, Interconnects |
| Family： |
Terminals - Spade Connectors |
| Series： |
PIDG, AMP |
| Packaging ： |
Tape & Reel (TR) |
| Terminal Type： |
Flanged |
| Stud/Tab Size： |
10 Stud |
| Width - Outer Edges： |
0.296" (7.52mm) |
| Length - Overall： |
0.768" (19.51mm) |
| Mounting Type： |
Free Hanging (In-Line) |
| Termination： |
Crimp |
| Wire Gauge： |
16-22 AWG |
| Insulation： |
Insulated |
| Features： |
Serrated Termination |
| Color： |
Red |
| Contact Finish： |
Tin |
| Contact Material： |
Copper |
| Insulation Diameter： |
0.105" ~ 0.140" (2.67mm ~ 3.56mm) |
| Material - Insulation： |
Polyamide (PA), Nylon |
| Length - Ring Center to Termination： |
0.203" (5.16mm) |
| Length - Termination： |
0.404" (10.26mm) |
| Tongue Inside Opening： |
0.197" (5.00mm) |
