1106417-1的详细信息
| Datasheets： | |
|---|---|
| 1106417： | |
| RoHS Information： | |
| 1106417-1 Statement of Compliance： | |
| RoHS 2 Statement： | |
| 3D Model： | |
| 1106417-1.pdf： | |
| Standard Package ： | 40 |
| Category： | Connectors, Interconnects |
| Family： | Heavy Duty Connectors - Housings, Hoods, Bases |
| Series： | HB.6, HTS |
| Packaging ： | Bulk |
| Connector Type： | Hood - Coupling |
| Style： | Bottom Entry |
| Size： | 3 |
| Lock Location： | Side Clip on Hood Top |
| Thread Size： | M25 |
| Size / Dimension： | 2.362" L x 1.693" W x 2.106" H (60.00mm x 43.00mm x 53.50mm) |
| Housing Color： | Gray |
| Features： | Cable to Cable |
| Ingress Protection： | IP65 - Dust Tight, Water Resistant |
| Housing Material： | Aluminum Alloy, Die Cast |
| Housing Finish： | Powder Coated |
| Operating Temperature： | - |
| For Use With： | A117063-ND - INSERT FEMALE 10POS+1GND CRIMPA117062-ND - INSERT MALE 10POS+1GND CRIMPA108053-ND - INSERT FEMALE 8POS+1GND CRIMP7-1103635-1-ND - INSERT FEMALE 6POS+1GND CLAMP7-1103634-1-ND - INSERT MALE 6POS+1GND CLAMP2-1104000-3-ND - INSERT MALE 8POS+1GND CRIMPA106835-ND - INSERT MALE 24POS+1GND CRIMPA106840-ND - INSERT MALE 6POS+1GND CRIMPA106828-ND - INSERT MALE 16POS+1GND CRIMP2-1103635-3-ND - INSERT FEMALE 6POS+1GND CRIMP2-1103007-3-ND - INSERT FEMALE 16POS+1GND CRIMP2-1103202-3-ND - INSERT FEMALE 24POS+1GND CRIMPA106816-ND - INSERT FEMALE 6POS+1GND SCREWA106815-ND - INSERT MALE 6POS+1GND SCREW |
| Associated Product： | 1103250-8-ND - CONN FRAME SIZE 3 MDL1103250-7-ND - CONN FRAME SIZE 3 MDLA106826-ND - CONN CABLE FITTING M25 METAL1108784-1-ND - CONN FRAME SIZE 3 MDL |
