1106437-1的详细信息
| Datasheets： | |
|---|---|
| 1106437： | |
| RoHS Information： | |
| 1106437-1 Statement of Compliance： | |
| RoHS 2 Statement： | |
| Standard Package ： | 40 |
| Category： | Connectors, Interconnects |
| Family： | Heavy Duty Connectors - Housings, Hoods, Bases |
| Series： | HA.16, HTS |
| Packaging ： | Bulk |
| Connector Type： | Hood - Coupling |
| Style： | Bottom Entry |
| Size： | 5 |
| Lock Location： | Side Clip on Hood Top |
| Thread Size： | M20 |
| Size / Dimension： | 3.130" L x 1.142" W x 2.039" H (79.50mm x 29.00mm x 51.80mm) |
| Housing Color： | Gray |
| Features： | Cable to Cable |
| Ingress Protection： | IP65 - Dust Tight, Water Resistant |
| Housing Material： | Aluminum Alloy, Die Cast |
| Housing Finish： | Powder Coated |
| Operating Temperature： | - |
| For Use With： | 7-1103417-1-ND - INSERT FEMALE 16POS+1GND CLAMP2-1103417-9-ND - INSERT FEMALE 16POS+1GND CRIMP2-1103417-8-ND - INSERT FEMALE 16POS+1GND CRIMP2-1103417-7-ND - INSERT FEMALE 16POS+1GND CRIMP2-1103417-3-ND - INSERT FEMALE 16POS+1GND CRIMP7-1103416-1-ND - INSERT MALE 16POS+1GND CLAMP2-1103416-9-ND - INSERT MALE 16POS+1GND CRIMP2-1103416-8-ND - INSERT MALE 16POS+1GND CRIMP2-1103416-7-ND - INSERT MALE 16POS+1GND CRIMP2-1103416-3-ND - INSERT MALE 16POS+1GND CRIMPA106832-ND - INSERT MALE 25POS+1GND CRIMP2-1103010-3-ND - INSERT MALE 25POS+1GND CRIMPA113064-ND - INSERT FEMALE 25POS+1GND CRIMP2-1103011-3-ND - INSERT FEMALE 25POS+1GND CRIMPA106813-ND - INSERT MALE 16POS+1GND SCREWA106814-ND - INSERT FEMALE 16POS+1GND SCREWA111813-ND - INSERT FEMALE 16POS+1GND SCREWA106812-ND - INSERT MALE 16POS+1GND SCREW |
| Associated Product： | A113060-ND - CONN CABLE FITTING M202-1102771-0-ND - CONN CABLE GLAND M20 IP68A106825-ND - CONN CABLE GLAND M20 IP68 |
