1460346的详细信息
| Datasheets： | |
|---|---|
| 1460346： | |
| Standard Package ： | 10 |
| Category： | Connectors, Interconnects |
| Family： | Heavy Duty Connectors - Housings, Hoods, Bases |
| Series： | HEAVYCON® B |
| Packaging ： | Bulk |
| Connector Type： | Hood |
| Style： | Side Entry |
| Size： | B6 |
| Lock Location： | Side Clip on Base Bottom |
| Thread Size： | M20 |
| Size / Dimension： | 2.362" L x 1.693" W x 2.205" H (60.00mm x 43.00mm x 56.00mm) |
| Housing Color： | Gray |
| Features： | - |
| Ingress Protection： | IP65 - Dust Tight, Water Resistant |
| Housing Material： | Aluminum, Die Cast |
| Housing Finish： | Powder Coated |
| Operating Temperature： | -40°C ~ 125°C |
| For Use With： | 1648380-ND - INSERT MALE 6POS TERMINAL BLOCK1648377-ND - INSERT FEMALE 6POS TERM BLOCK1648364-ND - INSERT MALE 6POS TERMINAL BLOCK1648157-ND - INSERT MALE 6POS+1GND CRIMP1648072-ND - INSERT MALE 6POS+1GND TERM BLOCK1648066-ND - INSERT FEMALE 6P+1GND TERM BLOCK1648024-ND - INSERT MALE 6POS+1GND TERM BLOCK1647365-ND - INSERT FEMALE 6POS+1GND PUSH IN1648131-ND - INSERT MALE 6POS+1GND PUSH IN1648144-ND - INSERT FEMALE 6POS+1GND PUSH IN1648351-ND - INSERT FEMALE 6POS TERM BLOCK1687860-ND - INSERT MALE 6POS+1GND PUSH IN277-4372-ND - INSERT MALE 24POS CRIMP277-4539-ND - INSERT FEMALE 24POS CRIMP277-8538-ND - INSERT MALE 10POS CRIMP1687435-ND - INSERT FEMALE 10POS CRIMP277-4381-ND - INSERT MALE 6POS TENSION CLAMP277-4380-ND - INSERT FEMALE 6POS TENSION CLAMP1605556-ND - INSERT FEMALE 6POS IDC1605611-ND - INSERT MALE 6POS IDC277-4351-ND - INSERT MALE 6POS SCREW277-4389-ND - INSERT FEMALE 6POS SCREW1648018-ND - INSERT FEMALE 6P+1GND TERM BLOCK277-4128-ND - INSERT MALE 6POS SCREW277-4130-ND - INSERT FEMALE 6POS SCREW |
| Associated Product： | 1584017-ND - CONN SCREW METAL277-4471-ND - CABLE RELIEF 16MM277-4664-ND - CABLE RELIEF 13MM277-4384-ND - CABLE RELIEF 13MM |
| Other Names： | HC-B 6-TFL-N-O1STM20S |
