1666710000的详细信息
| Datasheets： | |
|---|---|
| ConCept Series： | |
| 1666710000 Drawing： | |
| 1666710000： | |
| Product Photos： | |
| 1666710000： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Heavy Duty Connectors - Housings, Hoods, Bases |
| Series： | RockStar® |
| Packaging ： | Bulk |
| Connector Type： | Hood |
| Style： | Side Entry |
| Size： | 9 |
| Lock Location： | Side Clip on Base Bottom |
| Thread Size： | PG29 |
| Size / Dimension： | 3.701" L x 3.248" W x 3.110" H (94.00mm x 82.50mm x 79.00mm) |
| Housing Color： | Gray |
| Features： | - |
| Ingress Protection： | IP65 - Dust Tight, Water Resistant |
| Housing Material： | Aluminum, Die Cast |
| Housing Finish： | Powder Coated |
| Operating Temperature： | - |
| For Use With： | 1896850000-ND - INSERT MALE 16POS+1GND PUSH IN1896840000-ND - INSERT MALE 16POS+1GND PUSH IN1896830000-ND - INSERT MALE 16POS+1GND PUSH IN1896820000-ND - INSERT FEMALE 16POS+1GND PUSH IN1896810000-ND - INSERT FEMALE 16POS+1GND PUSH IN1896800000-ND - INSERT FEMALE 16POS+1GND PUSH IN1876040000-ND - INSERT FEMALE 16POS+1GND CRIMP1875630000-ND - INSERT MALE 16POS+1GND CRIMP1875620000-ND - INSERT MALE 16POS+1GND CRIMP1875540000-ND - INSERT FEMALE 16POS+1GND CRIMP1873890000-ND - INSERT MALE 16POS+1GND CRIMP1873880000-ND - INSERT FEMALE 16POS+1GND CRIMP1651020000-ND - INSERT FEMALE 16POS+1GND SCREW1650990000-ND - INSERT MALE 16POS+1GND SCREW281-2234-ND - INSERT FEMALE 16POS+1GND SCREW281-2235-ND - INSERT MALE 16POS+1GND SCREW281-2232-ND - INSERT FEMALE 16POS+1GND SCREW281-2233-ND - INSERT MALE 16POS+1GND SCREW |
| Other Names： | 1666710000-ND281-2363HDC 48A TSLU 1PG29G |
