1788800000的详细信息
| Datasheets： | |
|---|---|
| 1788800000： | |
| 1788800000 Drawing： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | Heavy Duty Connectors - Housings, Hoods, Bases |
| Series： | RockStar® |
| Packaging ： | Bulk |
| Connector Type： | Hood - Coupling |
| Style： | Bottom Entry |
| Size： | 5 |
| Lock Location： | Side Clip on Hood Top |
| Thread Size： | M25 |
| Size / Dimension： | 3.110" L x 1.279" W x 2.087" H (79.00mm x 32.50mm x 53.00mm) |
| Housing Color： | Gray |
| Features： | Cable to Cable |
| Ingress Protection： | IP65 - Dust Tight, Water Resistant |
| Housing Material： | Aluminum, Die Cast |
| Housing Finish： | Powder Coated |
| Operating Temperature： | - |
| For Use With： | 1023050000-ND - INSERT FEMALE 25POS+1GND CRIMP1023040000-ND - INSERT MALE 25POS+1GND CRIMP1896830000-ND - INSERT MALE 16POS+1GND PUSH IN1896800000-ND - INSERT FEMALE 16POS+1GND PUSH IN1873890000-ND - INSERT MALE 16POS+1GND CRIMP1873880000-ND - INSERT FEMALE 16POS+1GND CRIMP1651020000-ND - INSERT FEMALE 16POS+1GND SCREW1650990000-ND - INSERT MALE 16POS+1GND SCREW281-2234-ND - INSERT FEMALE 16POS+1GND SCREW281-2235-ND - INSERT MALE 16POS+1GND SCREW281-2291-ND - INSERT FEMALE 25POS+1GND CRIMP281-2292-ND - INSERT MALE 25POS+1GND CRIMP281-2232-ND - INSERT FEMALE 16POS+1GND SCREW281-2233-ND - INSERT MALE 16POS+1GND SCREW |
| Associated Product： | 281-2242-ND - CONN COVER FOR HOOD HA SIZE 5 |
