| 型号： | 216398-4 |
| 厂商： |
TE Connectivity |
| 标准： |   |
| 分类： | 连接器 ， 背板连接器 - DIN 41612 |
| 描述： | 48p.iec-C male conn |
| 报错 收藏 赞 | |
216398-4的详细信息
| Datasheets： | |
|---|---|
| 216398 Drawing： | |
| Product Photos： | |
| 216398-4： | |
| Standard Package ： | 50 |
| Category： | Connectors, Interconnects |
| Family： | Backplane Connectors - DIN 41612 |
| Series： | Eurocard, AMP |
| Packaging ： | Tray |
| Connector Type： | Plug, Male Pins |
| Number of Positions： | 48 |
| Number of Positions Loaded： | All |
| Pitch： | 0.100" (2.54mm) |
| Number of Rows： | 3 |
| Style： | 1/2 C |
| Level, Class： | 2 |
| Mounting Type： | Through Hole, Right Angle |
| Termination： | Press-Fit |
| Features： | - |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 31.5µin (0.80µm) |
| Operating Temperature： | -55°C ~ 125°C |
| Current Rating： | - |
| Material Flammability Rating： | UL94 V-0 |
| Material - Insulation： | Polyester Thermoplastic |
| Mating Products： | A113950-ND - ASSY,RECEPT EUROCARD TYPE C/2A101934-ND - ASSY,RECEPT EUROCARD,TYPE C/21393642-9-ND - EUROCARD TYPE C2-1393641-5-ND - EUROCARD TYPE CA101994-ND - EUROCARD TYPE C2-1393640-1-ND - EUROCARD TYPE C1393640-7-ND - EUROCARD TYPE C4-1393637-4-ND - EUROCARD TYPE C5535091-5-ND - CONN RECEPT VERT 48 POS DIN PCBA32836-ND - CONN DIN RECEPT 48POS VERT PCBA32835-ND - CONN DIN RECEPT 48POS VERT PCBA32834-ND - CONN DIN RECEPT 48POS VERT PCBA1271-ND - CONN DIN RECEPT 48POS RT ANG PCB |
| Other Names： | 216398-4-ND2163984A102042 |
