2N3773G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | Transistors Bipolar - BJT |
| RoHS： | Yes |
| Brand： | ON Semiconductor |
| Configuration： | Single |
| Transistor Polarity： | NPN |
| Collector- Base Voltage VCBO： | 160 V |
| Collector- Emitter Voltage VCEO Max： | 140 V |
| Emitter- Base Voltage VEBO： | 7 V |
| Collector-Emitter Saturation Voltage： | 1.4 V |
| Maximum DC Collector Current： | 16 A |
| Maximum Operating Temperature： | + 200 C |
| Mounting Style： | Through Hole |
| Package / Case： | TO-204 |
| Continuous Collector Current： | 16 A |
| DC Collector/Base Gain hfe Min： | 15 |
| Maximum Power Dissipation： | 150 W |
| Minimum Operating Temperature： | - 65 C |
| Packaging： | Tray |
| Series： | 2N3773 |
| Factory Pack Quantity： | 100 |
2N3773G相关文档
- Simulation Model: Spice 3 model
- Simulation Model: Spice 2 model
- Simulation Model: Saber model
- Simulation Model: PSpice model
- Package Drawing: TO-204 (TO-3)
