3476/16 100的详细信息
| Datasheets： | |
|---|---|
| 3476 Series： | |
| Cable & Accessory Selection Guide： | |
| 3M Cable Properties-Internal Wiring： | |
| Product Photos： | |
| 3476/16 100： | |
| Standard Package ： | 5 |
| Category： | Cables, Wires |
| Family： | Flat Ribbon Cables |
| Series： | 3476 |
| Cable Type： | Flat Cable, Ground Plane |
| Number of Conductors： | 16 |
| Pitch： | 0.050" (1.27mm) |
| Length： | 100' (30.5m) |
| Wire Gauge： | 28 AWG |
| Conductor Strand： | 7 Strands / 36 AWG |
| Shielding： | Unshielded |
| Jacket Color： | Gray |
| Ribbon Thickness： | 0.047" (1.19mm) |
| Ribbon Width： | 1.050" (26.67mm) |
| Jacket (Insulation) Material： | Poly-Vinyl Chloride (PVC) |
| Voltage： | 300V |
| Operating Temperature： | -20°C ~ 105°C |
| Ratings： | UL Style 2682 |
| Features： | - |
| Conductor Material： | Copper, Tinned |
| Insulation Resistance： | 10 GOhm |
| First Conductor Mark： | Red |
| Current Rating： | - |
| Dynamic Catalog： | 3476 Series |
| Associated Product： | 3557-ND - CABLE NOTCHER |
| Other Names： | 00051119931051051119931053476/16 (100')3476/16 (100')-ND3476/16 100-ND80001216789MB16PC-100 |
