5-1761617-5的详细信息
| Datasheets： | |
|---|---|
| 1761617： | |
| Product Photos： | |
| 5-1761617-5： | |
| RoHS Information： | |
| 5-1761617-5 Statement of Compliance： | |
| RoHS 2 Statement： | |
| Catalog Drawings： | |
| STEP-Z Receptacle： | |
| 3D Model： | |
| 5-1761617-5.pdf： | |
| Standard Package ： | 20 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
| Series： | STEP-Z, AMP |
| Packaging ： | Tray |
| Connector Type： | Differential Pair Array, Female |
| Number of Positions： | 296 signal (148 pair) |
| Pitch： | 0.051" (1.30mm) |
| Number of Rows： | 18 |
| Mounting Type： | Surface Mount |
| Features： | - |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 30µin (0.76µm) |
| Mated Stacking Heights： | 15mm, 17mm, 18mm, 20mm, 25mm, 30mm |
| Height Above Board： | 0.419" (10.64mm) |
| Dynamic Catalog： | STEP-Z Series |
| Mating Products： | 6-1761616-2-ND - CONN PLUG 296POS STEP-Z 12MM AUA99365-ND - CONN PLUG 296POS STEP-Z 25MM AUA99363-ND - CONN PLUG 296POS STEP-Z 20MM AUA99360-ND - CONN PLUG 296POS STEP-Z 15MM AUA99357-ND - CONN PLUG 296POS STEP-Z 13MM AUA99354-ND - CONN PLUG 296POS STEP-Z 10MM AU |
| Other Names： | 517616175A99348 |
