5223524-1的详细信息
| Datasheets： | |
|---|---|
| 5223524： | |
| Product Photos： | |
| 5223524-1： | |
| RoHS Information： | |
| 5223524-1 Statement of Compliance： | |
| RoHS 2 Statement： | |
| 3D Model： | |
| 5223524-1.pdf： | |
| Standard Package ： | 48 |
| Category： | Connectors, Interconnects |
| Family： | Backplane Connectors - Specialized |
| Series： | Z-PACK, AMP |
| Packaging ： | Tube |
| Connector Usage： | - |
| Connector Type： | Header, Male Pins |
| Connector Style： | Futurebus |
| Number of Positions： | 30 |
| Number of Positions Loaded： | All |
| Pitch： | 0.079" (2.00mm) |
| Number of Rows： | 5 |
| Number of Columns： | - |
| Mounting Type： | Board Edge, Through Hole, Right Angle |
| Termination： | Press-Fit |
| Contact Layout, Typical： | - |
| Features： | Board Guide |
| Contact Finish： | Gold |
| Contact Finish Thickness： | - |
| Color： | Natural |
| Current Rating： | - |
| Material Flammability Rating： | UL94 V-0 |
| Operating Temperature： | -55°C ~ 125°C |
| Voltage Rating： | 30V |
| Mating Products： | 5223668-1-ND - 2MM FB,5RV,REC,ASY,030,PF,3.205223652-1-ND - 2MM FB,5RV,REC,ASY,030,PF,4.25A97842-ND - CONN RCPT 30POS R/A 2MM PRESSFITA97840-ND - CONN RCPT 30POS R/A 2MM SOLDERA97838-ND - CONN RCPT 30POS R/A 2MM SOLDER223008-1-ND - CONN 2MM FB RCPT 30POS R/A GOLD |
| Other Names： | 5223524-1-NDA115346 |
