536295-1的详细信息
| Datasheets： | |
|---|---|
| 536295： | |
| Product Photos： | |
| 536295-1： | |
| RoHS Information： | |
| 536295-1 Statement of Compliance： | |
| 3D Model： | |
| 536295-1.pdf： | |
| Standard Package ： | 390 |
| Category： | Connectors, Interconnects |
| Family： | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets |
| Series： | Micro-Strip, AMP |
| Packaging ： | Tray |
| Connector Type： | Receptacle |
| Number of Positions： | 40 |
| Number of Positions Loaded： | All |
| Pitch： | 0.050" (1.27mm) |
| Number of Rows： | 2 |
| Row Spacing： | 0.100" (2.54mm) |
| Height Stacking (Mating)： | - |
| Height Above Board： | 0.315" (8.00mm) |
| Mounting Type： | Through Hole, Right Angle |
| Termination： | Solder |
| Contact Finish： | Gold |
| Contact Finish Thickness： | 30µin (0.76µm) |
| Features： | Ground Bus (Plane) |
| Color： | Natural |
| Mating Products： | 5536275-7-ND - CONN HEADER 40POS VERT 30GOLD5536274-1-ND - CONN HEADER 40POS VERT 30GOLD5536273-1-ND - CONN PLUG VERT 40POS 30AU PCB5149014-1-ND - CONN PLUG 40POS VERT 30GOLD5149013-1-ND - CONN PLUG 40POS VERT 30GOLDA110817-ND - CONN PLUG 40POS VERT 30GOLD PCB5149009-1-ND - CONN PLUG 40POS VERT SOLDER5536280-1-ND - CONN PLUG 40POS VERT GOLDA115385-ND - CONN PLUG 40POS VERT .050 SOLDER |
