6204008的详细信息
| Datasheets： | |
|---|---|
| Screw Connection Din Terminal Blocks： | |
| Standard Package ： | 50 |
| Category： | Connectors, Interconnects |
| Family： | Terminal Blocks - Din Rail, Channel |
| Series： | - |
| Type： | Feed Through |
| Disconnect Type： | - |
| Number of Positions： | 4 |
| Number of Levels： | 2 |
| Terminal - Width： | 6.0mm |
| Termination Style： | Screw |
| Current - IEC： | 32A |
| Voltage - IEC： | 800V |
| Current - UL： | 30A |
| Voltage - UL： | 600V |
| Wire Gauge or Range - AWG： | 10-24 AWG |
| Wire Gauge or Range - mm²： | 0.5-4mm² |
| Features： | - |
| Color： | Red |
| Fuse Type： | - |
| Material - Insulation： | Polyamide (PA66), Nylon 6/6 |
| Material Flammability Rating： | UL94 V-0 |
| Stripping Length： | 10mm |
| Associated Product： | 6800501-ND - CONN TEST PLUG ADAPTER RED6800500-ND - CONN TEST PLUG ADAPTER BLACK |
