74HC04N,652的详细信息
Manufacturer: | NXP |
---|---|
Product Category: | Inverters |
RoHS: | Yes |
Brand: | NXP Semiconductors |
Number of Circuits: | 6 |
Logic Family: | 74HC |
Logic Type: | CMOS |
Supply Voltage - Max: | 6 V |
Supply Voltage - Min: | 2 V |
Maximum Operating Temperature: | + 125 C |
Mounting Style: | Through Hole |
Package / Case: | PDIP-14 |
Packaging: | Tube |
High Level Output Current: | - 5.2 mA |
Low Level Output Current: | 5.2 mA |
Minimum Operating Temperature: | - 40 C |
Propagation Delay Time: | 85 ns, 17 ns, 14 ns |
Factory Pack Quantity: | 25 |
Part # Aliases: | 74HC04N |
74HC04; 74HCT04
Hex inverter
Rev. 4 — 3 August 2012
Product data sheet
1. General description
The 74HC04; 74HCT04 is a hex inverter. The inputs include clamp diodes that enable the
use of current limiting resistors to interface inputs to voltages in excess of VCC
.
2. Features and benefits
Complies with JEDEC standard JESD7A
Complies with JEDEC standard JESD8-1A
Input levels:
For 74HC04: CMOS level
For 74HCT04: TTL level
ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
Multiple package options
Specified from 40 C to +85 C and from 40 C to +125 C
3. Ordering information
Table 1.
Type number Package
Temperature range Name
Ordering information
Description
Version
74HC04N
40 C to +125 C
DIP14
plastic dual in-line package; 14 leads (300 mil)
SOT27-1
74HCT04N
74HC04D
40 C to +125 C
40 C to +125 C
40 C to +125 C
40 C to +125 C
SO14
plastic small outline package; 14 leads; body width
3.9 mm
SOT108-1
74HCT04D
74HC04DB
74HCT04DB
74HC04PW
74HCT04PW
74HC04BQ
74HCT04BQ
SSOP14
TSSOP14
DHVQFN14
plastic shrink small outline package; 14 leads; body SOT337-1
width 5.3 mm
plastic thin shrink small outline package; 14 leads;
body width 4.4 mm
SOT402-1
plastic dual in-line compatible thermal enhanced very SOT762-1
thin quad flat package; no leads; 14 terminals;
body 2.5 3 0.85 mm
