74HC595D,112的详细信息
Manufacturer: | NXP |
---|---|
Product Category: | Counter Shift Registers |
RoHS: | Yes |
Brand: | NXP Semiconductors |
Counting Sequence: | Serial to Serial/Parallel |
Number of Circuits: | 1 |
Package / Case: | SOT-109 |
Logic Family: | HC |
Logic Type: | CMOS |
Number of Input Lines: | 1 |
Output Type: | 3-State |
Propagation Delay Time: | 175 ns, 35 ns, 30 ns |
Maximum Operating Temperature: | + 125 C |
Minimum Operating Temperature: | - 40 C |
Packaging: | Tube |
Function: | Shift Register |
Mounting Style: | SMD/SMT |
Number of Output Lines: | 9 |
Operating Supply Voltage: | 5 V |
Factory Pack Quantity: | 50 |
Supply Voltage - Max: | 6 V |
Supply Voltage - Min: | 2 V |
Part # Aliases: | 74HC595D |
74HC595; 74HCT595
8-bit serial-in, serial or parallel-out shift register with output
latches; 3-state
Rev. 6 — 12 December 2011
Product data sheet
1. General description
The 74HC595; 74HCT595 are high-speed Si-gate CMOS devices and are pin compatible
with Low-power Schottky TTL (LSTTL). They are specified in compliance with JEDEC
standard No. 7A.
The 74HC595; 74HCT595 are 8-stage serial shift registers with a storage register and
3-state outputs. The registers have separate clocks.
Data is shifted on the positive-going transitions of the shift register clock input (SHCP).
The data in each register is transferred to the storage register on a positive-going
transition of the storage register clock input (STCP). If both clocks are connected together,
the shift register will always be one clock pulse ahead of the storage register.
The shift register has a serial input (DS) and a serial standard output (Q7S) for cascading.
It is also provided with asynchronous reset (active LOW) for all 8 shift register stages. The
storage register has 8 parallel 3-state bus driver outputs. Data in the storage register
appears at the output whenever the output enable input (OE) is LOW.
2. Features and benefits
8-bit serial input
8-bit serial or parallel output
Storage register with 3-state outputs
Shift register with direct clear
100 MHz (typical) shift out frequency
ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
Multiple package options
Specified from 40 C to +85 C and from 40 C to +125 C
3. Applications
Serial-to-parallel data conversion
Remote control holding register
