The SN74LS194A is a High Speed 4-Bit Bidirectional Universal
Shift Register. As a high speed multifunctional sequential building
block, it is useful in a wide variety of applications. It may be used in
serial-serial, shift left, shift right, serial-parallel, parallel-serial, and
parallel-parallel data register transfers. The LS194A is similar in
operation to the LS195A Universal Shift Register, with added features
of shift left without external connections and hold (do nothing) modes
of operation. It utilizes the Schottky diode clamped process to achieve
high speeds and is fully compatible with all ON Semiconductor TTL
families.
LOW
POWER
SCHOTTKY
• Typical Shift Frequency of 36 MHz
• Asynchronous Master Reset
• Hold (Do Nothing) Mode
• Fully Synchronous Serial or Parallel Data Transfers
• Input Clamp Diodes Limit High Speed Termination Effects
16
1
GUARANTEED OPERATING RANGES
PLASTIC
N SUFFIX
CASE 648
Symbol
Parameter
Supply Voltage
Min
4.75
0
Typ
5.0
25
Max
5.25
70
Unit
V
V
CC
T
A
Operating Ambient
Temperature Range
°C
I
Output Current – High
Output Current – Low
–0.4
8.0
mA
mA
OH
16
I
OL
1
SOIC
D SUFFIX
CASE 751B
ORDERING INFORMATION
Device
Package
16 Pin DIP
16 Pin
Shipping
SN74LS194AN
SN74LS194AD
2000 Units/Box
2500/Tape & Reel
Semiconductor Components Industries, LLC, 1999
1
Publication Order Number:
December, 1999 – Rev. 6
SN74LS194A/D
