NXP Semiconductors
74LVC00ABQ-Q100X的详细信息
| Datasheets： | |
|---|---|
| 74LVC00A-Q100： | |
| Product Photos： | |
| 14-DHVQFN： | |
| Standard Package ： | 3,000 |
| Category： | Integrated Circuits (ICs) |
| Family： | Logic - Gates and Inverters |
| Series： | 74LVC |
| Packaging ： | Tape & Reel (TR) |
| Logic Type： | NAND Gate |
| Number of Circuits： | 4 |
| Number of Inputs： | 2 |
| Features： | - |
| Voltage - Supply： | 1.2 V ~ 3.6 V |
| Current - Quiescent (Max)： | 40µA |
| Current - Output High, Low： | 24mA, 24mA |
| Logic Level - Low： | 0.7 V ~ 0.8 V |
| Logic Level - High： | 1.7 V ~ 2 V |
| Max Propagation Delay @ V, Max CL： | 2ns @ 3.3V, 50pF |
| Operating Temperature： | -40°C ~ 125°C |
| Mounting Type： | Surface Mount |
| Supplier Device Package： | 14-DQFN (3x2.5) |
| Package / Case： | 14-VFQFN Exposed Pad |
| Other Names： | 935300352115 |
