750871013的详细信息
| Datasheets： | |
|---|---|
| 750871013： | |
| Product Photos： | |
| 750871013： | |
| Standard Package ： | 100 |
| Category： | Transformers |
| Family： | Switching Converter, SMPS Transformers |
| Series： | WE-UNIT |
| Packaging ： | Tray |
| Type： | For AC/DC Converters |
| Applications： | LED Drivers, AC/DC SMPS |
| Intended Chipset： | TEA1521T |
| Voltage - Primary： | 115 ~ 390V |
| Voltage - Auxillary： | 15V @ 30mA |
| Voltage - Isolation： | 4000Vrms |
| Frequency： | 100kHz |
| Operating Temperature： | -40°C ~ 125°C |
| Mounting Type： | Through Hole |
| Size / Dimension： | 19.69mm L x 13.72mm W |
| Height - Seated (Max)： | 10.16mm |
| Chipset Manufacturer： | NXP Semiconductors |
| For Use With： | TEA1521T/N2,118-ND - IC CTLR SMPS PS SW MODE 14SOIC568-2334-6-ND - IC CTRLR SMPS OVP OTP HV 14SOIC568-2334-1-ND - IC CTRLR SMPS OVP OTP HV 14SOIC568-2334-2-ND - IC CTRLR SMPS OVP OTP HV 14SOIC |
| Other Names： | 732-2238 |
