787169-7的详细信息
| Datasheets： | |
|---|---|
| 787169： | |
| Product Photos： | |
| 787169-7： | |
| RoHS Information： | |
| 787169-7 Statement of Compliance： | |
| Catalog Drawings： | |
| Right Angle Receptacle WO Rails： | |
| 3D Model： | |
| 787169-7.pdf： | |
| Standard Package ： | 8 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub Connectors |
| Series： | AMPLIMITE .050 III, AMP |
| Packaging ： | Tube |
| Connector Style： | D-Type |
| Connector Type： | Receptacle, Female Sockets |
| Number of Positions： | 68 |
| Number of Rows： | 2 |
| Shell Size, Connector Layout： | 0.050 Pitch x 0.100 Row to Row |
| Contact Type： | Signal |
| Mounting Type： | Panel Mount |
| Through Hole, Right Angle： | |
| Flange Feature： | Housing/Shell (4-40) |
| Termination： | Solder |
| Features： | Shielded |
| Shell Material, Finish： | Steel, Nickel Plated |
| Contact Finish： | Gold |
| Contact Finish Thickness： | Flash |
| Ingress Protection： | - |
| Operating Temperature： | -55°C ~ 105°C |
| Voltage Rating： | 30V |
| Current Rating： | 1A |
| Housing Material： | Thermoplastic |
| Color： | Black |
| Mating Products： | A31795-ND - CONN PLUG 68POS .050 IDC W/COVA31789-ND - CONN PLUG 68POS .050SR W/COVERA31787-ND - CONN PLUG 68POS .050SR 3PC GRAYA31786-ND - CONN PLUG 68POS .050SR 3PC BLK |
| Other Names： | 787169-7-NDA23729 |
