型号:

9823 BK005

厂商: Alpha Wire Alpha Wire
标准:
分类: 电线和电缆同轴电缆 (RF)
描述: cable coax twinax 22awg BK 100'
报错 收藏

Datasheet下载地址

厂商下载 >>

9823 BK005的详细信息

Datasheets:
Part Number Ordering Guide:
Manhattan Elect Cables Brochure:
Manhattan Elect Cable Catalog:
9823 Spec Sheet:
Product Training Modules:
Basics of Wire and Cable:
Standard Package : 1
Category: Cables, Wires
Family: Coaxial Cables (RF)
Series: -
Cable Type: Twinaxial
Cable Group: -
Wire Gauge: 22 AWG
Conductor Strand: 19 Strands / 34 AWG
Jacket (Insulation) Material: Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Diameter: 0.329" (8.36mm)
Shield Type: Foil
Impedance: 150 Ohm
Length: 100' (30.5m)
Color: Black
Usage: -
Features: -
Conductor Material: Copper, Tinned
Dielectric Material: Cellular (Foam) Polyethylene (Cellular FPE)
Dielectric Diameter: 0.120" (3.05mm)
Shield Material: Aluminum
Shield Coverage: 100%
VoP, Velocity of Propagation: 78
Operating Temperature: -20°C ~ 60°C
