Texas Instruments
ADS41B29IRGZ25的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 1 Channel |
| Brand： | Texas Instruments |
| Architecture： | Pipeline |
| Conversion Rate： | 250 MS/s |
| Resolution： | 12 bit |
| Input Type： | Differential |
| Operating Supply Voltage： | 1.7 V to 1.9 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | VQFN-48 |
| Maximum Power Dissipation： | 7 mW |
| Number of Converters： | 1 |
| Packaging： | Reel |
| Series： | ADS41B29 |
| SNR： | 69 dB |
| Factory Pack Quantity： | 25 |
ADS41B29IRGZ25相关文档
- PCN: Conversion to smaller reel (13" to 7") and associated packing materials on Selected QFN Devices currently shipped in 13 reels
- Evaluation Kits: Wideband Transmit Signal Chain Evaluation Board & Reference Design
- Evaluation Kits: ADS4149 ADC Evaluation Module
- Evaluation Kits: Low Cost Data Capture Card
- Evaluation Kits: ADS41B29 Evaluation Module
- Evaluation Kits: TSW2200EVM: Low Cost Portable Power Supply
- Evaluation Kits: High Speed Data Capture and Pattern Generation Platform
- Function Diagram: fbd_sbas486e
- PCN: Add Cu as Alternative Wire Base Metal for Selected Device(s)
ADS41B29IRGZ25应用笔记
- Band-Pass Filter Design Techniques for High-Speed ADCs
- Interleaving Analog-to-Digital Converters
- Analog-to-Digital Converter Grounding Practices Affect System Performance
- CDCE72010 as a Clocking Solution for High-Speed Analog-to-Digital Converters
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Phase Noise Performance and Jitter Cleaning Ability of CDCE72010
- A Glossary of Analog-to-Digital Specifications and Performance Characteristics (Rev. B)
- Design Considerations for Avoiding Timing Errors during High-Speed ADC, LVDS Dat
- QFN Layout Guidelines
- What Designers Should Know About Data Converter Drift
- CDCE62005 as Clock Solution for High-Speed ADCs
- High-Speed, Analog-to-Digital Converter Basics
- Why Use Oversampling when Undersampling Can Do the Job? (Rev. A)
- Principles of Data Acquisition and Conversion
- Power Supply Design for the ADS41xx (Rev. A)
