ADS5121IZHK的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 8 Channel |
| Brand： | Texas Instruments |
| Architecture： | Pipeline |
| Conversion Rate： | 40000 kS/s |
| Resolution： | 10 bit |
| Input Type： | Differential |
| Interface Type： | Parallel |
| Operating Supply Voltage： | 1.8 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | BGA-257 Microstar |
| Maximum Power Dissipation： | 525 mW |
| Minimum Operating Temperature： | - 40 C |
| Number of Converters： | 8 |
| Packaging： | Tray |
| Series： | ADS5121 |
| SNR： | 60 dB |
| Factory Pack Quantity： | 90 |
| Voltage Reference： | Internal, External |
| Unit Weight： | 581.800 mg |
ADS5121IZHK相关文档
- PCN: TI - PCN - 7-23-10
- Evaluation Kits: TSW2200EVM: Low Cost Portable Power Supply
ADS5121IZHK应用笔记
- Smart Selection of ADC/DAC Enables Better Design of Software-Defined Radio
- Interfacing the VCA8617 with High-Speed ADCs
- Driving High-Speed ADCs: Circuit Topologies and System-Level Parameter (Rev. A)
- Why Use Oversampling when Undersampling Can Do the Job? (Rev. A)
- Design Considerations for Avoiding Timing Errors during High-Speed ADC, LVDS Dat
- Phase Noise Performance and Jitter Cleaning Ability of CDCE72010
- CDCE62005 as Clock Solution for High-Speed ADCs
- Principles of Data Acquisition and Conversion
- A Glossary of Analog-to-Digital Specifications and Performance Characteristics (Rev. B)
- CDCE72010 as a Clocking Solution for High-Speed Analog-to-Digital Converters
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Analog-to-Digital Converter Grounding Practices Affect System Performance
- What Designers Should Know About Data Converter Drift
- Interleaving Analog-to-Digital Converters
- Interfacing the VCA8613 with High-Speed ADCs
