ADS6223IRGZR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 2 Channel |
| Brand： | Texas Instruments |
| Architecture： | Pipeline |
| Conversion Rate： | 80000 kS/s |
| Resolution： | 12 bit |
| Input Type： | Differential |
| Interface Type： | 1-Wire, 2-Wire, LVDS, Serial |
| Operating Supply Voltage： | 3 V to 3.6 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | VQFN-48 |
| Development Kit： | ADS6223EVM |
| Maximum Power Dissipation： | 850 mW |
| Minimum Operating Temperature： | - 40 C |
| Number of Converters： | 2 |
| Packaging： | Reel |
| Series： | ADS6223 |
| SNR： | 71.4 dB |
| Factory Pack Quantity： | 2500 |
| Voltage Reference： | Internal, External |
| Unit Weight： | 138 mg |
