ADS62P44IRGCT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 2 Channel |
| Brand： | Texas Instruments |
| Architecture： | Pipeline |
| Conversion Rate： | 105000 kS/s |
| Resolution： | 14 bit |
| Input Type： | Differential |
| Interface Type： | LVDS, Parallel |
| Operating Supply Voltage： | 3.3 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | VQFN-64 |
| Development Kit： | ADS62P44EVM |
| Maximum Power Dissipation： | 792 mW |
| Minimum Operating Temperature： | - 40 C |
| Number of Converters： | 2 |
| Packaging： | Reel |
| Series： | ADS62P44 |
| SNR： | 74.5 dB |
| Factory Pack Quantity： | 250 |
| Voltage Reference： | Internal, External |
| Unit Weight： | 209.300 mg |
ADS62P44IRGCT相关文档
- PCN: Conversion to smaller reel (13" to 7") and associated packing materials on Selected QFN Devices currently shipped in 13 reels
- Evaluation Kits: Low Cost Data Capture Card
- Evaluation Kits: High Speed Data Capture and Pattern Generation Platform
- Evaluation Kits: TSW2200EVM: Low Cost Portable Power Supply
- Evaluation Kits: ADS62P44 Evaluation Module
- TINA Reference Design: ADS62Pxx Family TINA-TI Transient Reference Design
- SPICE Model: ADS62Pxx Family TINA-TI Transient Spice Model
- Evaluation Kits: ADS62P24 Evaluation Module
- Function Diagram: fbd_slas561c
- PCN: Add Cu as Alternative Wire Base Metal for Selected Device(s)
ADS62P44IRGCT应用笔记
- What Designers Should Know About Data Converter Drift
- Analog-to-Digital Converter Grounding Practices Affect System Performance
- Interleaving Analog-to-Digital Converters
- Principles of Data Acquisition and Conversion
- A Glossary of Analog-to-Digital Specifications and Performance Characteristics (Rev. B)
- Design Considerations for Avoiding Timing Errors during High-Speed ADC, LVDS Dat
- Phase Noise Performance and Jitter Cleaning Ability of CDCE72010
- CDCE62005 as Clock Solution for High-Speed ADCs
- QFN Layout Guidelines
- Driving High-Speed ADCs: Circuit Topologies and System-Level Parameter (Rev. A)
- Why Use Oversampling when Undersampling Can Do the Job? (Rev. A)
- Shelf-Life Evaluation of Lead-Free Component Finishes
- CDCE72010 as a Clocking Solution for High-Speed Analog-to-Digital Converters
- Band-Pass Filter Design Techniques for High-Speed ADCs
- Smart Selection of ADC/DAC Enables Better Design of Software-Defined Radio
