ADS7841P的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 4 Channel/2 Channel |
| Brand： | Texas Instruments |
| Architecture： | SAR |
| Conversion Rate： | 200 kS/s |
| Resolution： | 12 bit |
| Input Type： | Single-Ended/Differential |
| Interface Type： | Serial |
| Operating Supply Voltage： | 2.7 V to 5 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | Through Hole |
| Package / Case： | PDIP-16 |
| Maximum Power Dissipation： | 4.5 mW |
| Minimum Operating Temperature： | - 40 C |
| Number of Converters： | 1 |
| Packaging： | Tube |
| Series： | ADS7841 |
| SNR： | 72 dB |
| Factory Pack Quantity： | 25 |
| Voltage Reference： | External |
| Unit Weight： | 1.054 g |
ADS7841P应用笔记
- Principles of Data Acquisition and Conversion
- A Glossary of Analog-to-Digital Specifications and Performance Characteristics (Rev. B)
- Determining Minimum Acquisition Times for SAR ADCs, part 2
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Analog-to-Digital Converter Grounding Practices Affect System Performance
- Interleaving Analog-to-Digital Converters
- Using the ADS7841 and ADS7844 with 15-Clock Cycles
- What Designers Should Know About Data Converter Drift
- Apply TI TSC for Various and Multiple Functions
