ADS8505IBDBRG4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Analog to Digital Converters - ADC |
| RoHS： | Yes |
| Number of Channels： | 1 Channel |
| Brand： | Texas Instruments |
| Architecture： | SAR |
| Conversion Rate： | 250 kS/s |
| Resolution： | 16 bit |
| Input Type： | Single-Ended |
| Interface Type： | Parallel |
| Operating Supply Voltage： | 5 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SSOP-28 |
| Development Kit： | ADS8505EVM |
| Maximum Power Dissipation： | 100 mW |
| Minimum Operating Temperature： | - 40 C |
| Number of Converters： | 1 |
| Packaging： | Reel |
| Series： | ADS8505 |
| SNR： | 88 dB |
| Factory Pack Quantity： | 2000 |
| Voltage Reference： | Internal, External |
| Unit Weight： | 208.400 mg |
ADS8505IBDBRG4相关文档
- Evaluation Kits: ADS8505EVM Evaluation Module
ADS8505IBDBRG4应用笔记
- Analog-to-Digital Converter Grounding Practices Affect System Performance
- Interleaving Analog-to-Digital Converters
- What Designers Should Know About Data Converter Drift
- Shelf-Life Evaluation of Lead-Free Component Finishes
- A Glossary of Analog-to-Digital Specifications and Performance Characteristics (Rev. B)
- Upgrading from the ADS7804/05 to the ADS8504/05
- Determining Minimum Acquisition Times for SAR ADCs, part 1 (Rev. A)
- Controlling the ADS7805 With TMS320 Series DSPs
- Principles of Data Acquisition and Conversion
- Determining Minimum Acquisition Times for SAR ADCs, part 2
