APT30GN60BG的详细信息
| Datasheets： | |
|---|---|
| APT30GN60B(G)： | |
| Power Products Catalog： | |
| Product Photos： | |
| TO-247-3： | |
| Catalog Drawings： | |
| TO-247 Front： | |
| Standard Package ： | 30 |
| Category： | Discrete Semiconductor Products |
| Family： | IGBTs - Single |
| Series： | - |
| Packaging ： | Tube |
| IGBT Type： | Trench and Field Stop |
| Voltage - Collector Emitter Breakdown (Max)： | 600V |
| Current - Collector (Ic) (Max)： | 63A |
| Current - Collector Pulsed (Icm)： | 90A |
| Vce(on) (Max) @ Vge, Ic： | 1.9V @ 15V, 30A |
| Power - Max： | 203W |
| Switching Energy： | 525µJ (on), 700µJ (off) |
| Input Type： | Standard |
| Gate Charge： | 165nC |
| Td (on/off) @ 25°C： | 12ns/155ns |
| Test Condition： | 400V, 30A, 4.3 Ohm, 15V |
| Reverse Recovery Time (trr)： | - |
| Package / Case： | TO-247-3 |
| Mounting Type： | Through Hole |
| Supplier Device Package： | TO-247 [B] |
| Dynamic Catalog： | Standard IGBTs |
| Other Names： | APT30GN60BGMIAPT30GN60BGMI-ND |
