APT64GA90B2D30的详细信息
| Datasheets： | |
|---|---|
| APT64GA90x(2)D30： | |
| Product Photos： | |
| TO-247-3： | |
| Standard Package ： | 30 |
| Category： | Discrete Semiconductor Products |
| Family： | IGBTs - Single |
| Series： | POWER MOS 8™ |
| Packaging ： | Tube |
| IGBT Type： | PT |
| Voltage - Collector Emitter Breakdown (Max)： | 900V |
| Current - Collector (Ic) (Max)： | 117A |
| Current - Collector Pulsed (Icm)： | 193A |
| Vce(on) (Max) @ Vge, Ic： | 3.1V @ 15V, 38A |
| Power - Max： | 500W |
| Switching Energy： | 1192µJ (on), 1088µJ (off) |
| Input Type： | Standard |
| Gate Charge： | 162nC |
| Td (on/off) @ 25°C： | 18ns/131ns |
| Test Condition： | 600V, 38A, 4.7 Ohm, 15V |
| Reverse Recovery Time (trr)： | - |
| Package / Case： | TO-247-3 Variant |
| Mounting Type： | Through Hole |
| Supplier Device Package： | * |
| Dynamic Catalog： | Standard IGBTs |
