ATTINY10-TS8R的详细信息
| Manufacturer： | Atmel |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| Core： | AVR |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 12 MHz |
| Program Memory Size： | 1 kB |
| Data RAM Size： | 32 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.8 V to 5.5 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | SOT-23-6 |
| Mounting Style： | SMD/SMT |
| A/D Bit Size： | 8 bit |
| A/D Channels Available： | 4 |
| Brand： | Atmel |
| Data RAM Type： | SRAM |
| Interface Type： | ISP |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 4 |
| Number of Timers： | 1 |
| On-Chip DAC： | Yes |
| Packaging： | Reel |
| Processor Series： | tinyAVR |
| Program Memory Type： | Flash |
| Series： | ATTINY 10 |
| Factory Pack Quantity： | 4500 |
| Tradename： | ATTINY |
