ATTINY167-XU的详细信息
| Manufacturer： | Atmel |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| Core： | AVR |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 16 MHz |
| Program Memory Size： | 16 kB |
| Data RAM Size： | 512 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.8 V to 5.5 V |
| Maximum Operating Temperature： | + 150 C |
| Package / Case： | TSSOP-20 |
| Mounting Style： | SMD/SMT |
| Brand： | Atmel |
| Data RAM Type： | SRAM |
| Interface Type： | SPI, USI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 16 |
| Number of Timers： | 3 |
| Processor Series： | tinyAVR |
| Program Memory Type： | Flash |
| Series： | ATTINY 167 |
| Factory Pack Quantity： | 74 |
| Tradename： | ATTINY |
