ATmega168PA-PU的详细信息
| Manufacturer： | Atmel |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | Atmel |
| Core： | AVR |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 20 MHz |
| Program Memory Size： | 16 kB |
| Data RAM Size： | 1 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.8 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | PDIP-28 |
| Mounting Style： | Through Hole |
| Data RAM Type： | SRAM |
| Interface Type： | SPI, TWI, UART |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 23 |
| Processor Series： | megaAVR |
| Program Memory Type： | Flash |
| Series： | ATMEGA 168PA |
| Factory Pack Quantity： | 14 |
| Tradename： | ATMEGA |
