BAV99的详细信息
Manufacturer: | Fairchild Semiconductor |
---|---|
Product Category: | Diodes - General Purpose, Power, Switching |
RoHS: | Yes |
Forward Continuous Current: | 0.2 A |
Max Surge Current: | 2 A |
Configuration: | Dual Series |
Recovery Time: | 6 ns |
Forward Voltage Drop: | 1.25 V at 0.15 A |
Mounting Style: | SMD/SMT |
Package / Case: | SOT-23 |
Packaging: | Reel |
Brand: | Fairchild Semiconductor |
Maximum Operating Temperature: | + 150 C |
Minimum Operating Temperature: | - 55 C |
Series: | BAV99 |
Factory Pack Quantity: | 3000 |
Part # Aliases: | BAV99_NL |
Unit Weight: | 25 mg |
April 2014
BAV99
200 mA 70 V High Conductance Ultra-Fast Switching
Diode
Features
Description
• High Conductance: I = 200 mA
The BAV99 is a 350 mW high-speed switching diode
array with series-pair diode configuration. It achieves
high-current conductivity, up to 200 mA, in a very small
7mm footprint. These features make the BAV99 optimal
for area-constrained applications that need a little extra
power capability.
F
• Fast Switching Speed: t < 6 ns Maximum
rr
• Small Plastic SOT-23 Package
• Series-Pair Configuration
2
For common cathode and common anode high-speed
switching diodes, explore Fairchild's BAV70 and BAW56.
Looking for more options in the SOT-23 package? Check
Fairchild's MMBD family.
Applications
• High-Speed Switching Applications
Connection Diagram
3
3
3
A7
2
1
2
1
2
1
SOT-23
Ordering Information
Part Number
BAV99
Marking
A7
Package
SOT-23 3L
SOT-23 3L
Packing Method
Tape and Reel, Reel 7 inch
Tape and Reel, Reel 13 inch
BAV99_D87Z
A7
© 2001 Fairchild Semiconductor Corporation
BAV99 Rev. 1.1.0
www.fairchildsemi.com
1
