| 型号： | CC1120RHBR |
| 厂商： |
 Texas Instruments |
| 标准： |   |
| 分类： | 半导体 ， 射频半导体 |
| 描述： | RF transceiver RF transceiver Hi perf |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
CC1120RHBR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | RF Transceiver |
| RoHS： | Yes |
| Frequency Range： | 164 MHz to 192 MHz, 274 MHz to 320 MHz, 410 MHz to 480 MHz |
| Maximum Data Rate： | 200 kb/s |
| Modulation Format： | 2-FSK, 2-GFSK, 4-FSK, 4-GFSK, MSK, OOK |
| Type： | Multiband |
| Operating Supply Voltage： | 2 V to 3.6 V |
| Maximum Operating Temperature： | + 85 C |
| Interface Type： | SPI |
| Package / Case： | VQFN-32 |
| Packaging： | Reel |
| Brand： | Texas Instruments |
| Minimum Operating Temperature： | - 40 C |
| Mounting Style： | SMD/SMT |
| Number of Receivers： | 1 |
| Number of Transmitters： | 1 |
| Sensitivity： | -110 dBm to - 127 dBm |
| Series： | CC1120 |
| Factory Pack Quantity： | 3000 |
| Supply Current Receiving： | 22 mA |
| Supply Current Transmitting： | 45 mA |
| Supply Voltage - Max： | 3.6 V |
| Supply Voltage - Min： | 2 V |
CC1120RHBR相关文档
- PCN: Conversion to Cu bond wire
- Evaluation Kits: CC1110 Meander Antenna 868/915 MHz Reference Design
- Evaluation Kits: Performance Line Development Kit
- Evaluation Kits: CC112x SKY65367 EM 30 dBm 169 MHz Reference Design
- Evaluation Kits: CC1120-CC1190EM 868MHz Reference Design
- Evaluation Kits: CC112x IPC 868/915MHz 2 layer Reference Design
- Evaluation Kits: CC1120EM 868/915 MHz Reference Design
- Evaluation Kits: CC112x SKY65313 EM 30 dBm 915 MHz Reference Design
- Evaluation Kits: CC1120 with TPS62730 EM 868 MHz Reference Design
- Evaluation Kits: CC1120 Evaluation Module Kit 169MHz
- Evaluation Kits: CC1120 Evaluation Module Kit 955MHz
- Evaluation Kits: CC1120EM 420/470 MHz Reference Design
- Evaluation Kits: CC1120EM 955 MHz Reference Design
- Evaluation Kits: CC1120EM 169 MHz Reference Design
- Evaluation Kits: CC1110 IIFA Antenna 868/915 MHz Reference Design
- Evaluation Kits: CC1120 Evaluation Module Kit 868-915MHz
- Evaluation Kits: EM Adapter BoosterPack
- Evaluation Kits: CC1120 Evaluation Module Kit 420-470MHz
- Evaluation Kits: CC112x IPC 868/915MHz 4 layer Reference Design
- Evaluation Kits: CC1120-CC1190EM 915MHz Reference Design
- Evaluation Kits: Evaluation Module (EM) Adaptor
