| 型号： | CC1125RHBR |
| 厂商： |
 Texas Instruments |
| 标准： |   |
| 分类： | 半导体 ， 射频半导体 |
| 描述： | RF transceiver ultra-Hi perf RF narrowbd transceiver |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
CC1125RHBR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | RF Transceiver |
| RoHS： | Yes |
| Frequency Range： | 164 MHz to 192 MHz, 274 MHz to 320 MHz, 410 MHz to 480 MHz, 820 MHz to 960 MHz |
| Maximum Data Rate： | 200 kb/s |
| Modulation Format： | 2-FSK, 2-GFSK, 4-FSK, 4-GFSK, MSK, OOK |
| Type： | Multiband |
| Operating Supply Voltage： | 2 V to 3.6 V |
| Maximum Operating Temperature： | + 85 C |
| Interface Type： | SPI |
| Package / Case： | VQFN-32 |
| Packaging： | Reel |
| Brand： | Texas Instruments |
| Development Kit： | CC1125DK |
| Minimum Operating Temperature： | - 40 C |
| Mounting Style： | SMD/SMT |
| Number of Receivers： | 1 |
| Number of Transmitters： | 1 |
| Sensitivity： | - 110 dBm, - 123 dBm, - 129 dBm |
| Series： | CC1125 |
| Factory Pack Quantity： | 3000 |
| Supply Current Receiving： | 26 mA |
| Supply Current Transmitting： | 47 mA |
| Supply Voltage - Max： | 3.6 V |
| Supply Voltage - Min： | 2 V |
CC1125RHBR相关文档
- PCN: Conversion to Cu bond wire
- Evaluation Kits: CC1125EM 868/915MHz Reference Design
- Evaluation Kits: CC1125 Development Kit
- Evaluation Kits: CC1125EM 420/470MHz Reference Design
- Evaluation Kits: CC1125EM 868MHz ETSI Cat 1 Reference Design
- Evaluation Kits: CC112x SKY65313 EM 30 dBm 915 MHz Reference Design
- Evaluation Kits: CC1125EM 169MHz Reference Design
- Evaluation Kits: ETSI Cat 1 RF Layout Reference Design
- Evaluation Kits: CC112x IPC 868/915MHz 4 layer Reference Design
- Evaluation Kits: CC112x IPC 868/915MHz 2 layer Reference Design
- Evaluation Kits: CC112x SKY65367 EM 30 dBm 169 MHz Reference Design
- Evaluation Kits: Performance Line Development Kit
CC1125RHBR应用笔记
- DN403 -- CC112x/CC120x On-Chip Temperature Sensor (Rev. B)
- AN112 -- Using CC1190 Front End With CC112x/CC120x Under EN 300 220 (Rev. C)
- AN121 ? Wireless M-Bus Implementation with CC112x/CC120x High Performance Transc
- AN110 ? Using CC1190 Front End with CC112x/CC120x under FCC 15.247 (Rev. B)
- DN040 -- Reduced Battery Current Using CC112x, CC1175_and CC1200 with TPS62730
- DN039 -- IPC for 868/915 MHz operation with the CC112x, CC117x and CC12xx
- DN035 -- Antenna Quick Guide (Rev. A)
- AN115 -- CC112x/CC1175/CC120x Operation in 274-320 MHz Frequency Band (Rev. A)
- CC112x/CC120x RX Sniff mode with Smart Preamble
- DN510 -- CC112X RSSI and CS Response Time
- DN038 -- Miniature Helical PCB Antenna for 868 MHz or 915/920 MHz
- CC112x/CC120x RX Sniff Mode (Rev. A)
- DN403 -- CC112x/CC120x On-Chip Temperature Sensor (Rev. C)
