CC2530F128RHAT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | RF System on a Chip - SoC |
| RoHS： | Yes |
| A/D Bit Size： | 12 bit |
| Type： | Zigbee |
| Core： | 8051 |
| Maximum Data Rate： | 250 kb/s |
| Output Power： | 4.5 dBm |
| Sensitivity： | - 97 dBm |
| Operating Supply Voltage： | 2 V to 3.6 V |
| Supply Current Receiving： | 24.3 mA |
| Supply Current Transmitting： | 33.5 mA |
| Program Memory Size： | 128 kB |
| Operating Temperature Range： | - 40 C to + 125 C |
| Package / Case： | VQFN-40 |
| A/D Channels Available： | 8 |
| Brand： | Texas Instruments |
| Data Bus Width： | 8 bit |
| Data RAM Size： | 8 kB |
| Frequency： | 2.4 GHz |
| Interface Type： | 2-Wire, SPI, UART |
| Mounting Style： | SMD/SMT |
| Number of Programmable I/Os： | 21 |
| Number of Timers： | 4 |
| On-Chip ADC： | Yes |
| Packaging： | Reel |
| Processor Series： | CC253 |
| Program Memory Type： | Flash |
| Series： | CC2530 |
| Factory Pack Quantity： | 250 |
| Unit Weight： | 78.700 mg |
CC2530F128RHAT相关文档
- PCN: Qualification of CLARK-AT as an additional assembly site for affected devices
- PCN: Add Cu Wire as Alternative Wire Base Metal for Select QFN Package Devices
- PCN: Conversion to smaller reel (13" to 7") and associated packing materials on Selected QFN Devices currently shipped in 13 reels
- Evaluation Kits: CC2533 Evaluation Module Kit
- Evaluation Kits: CC2531 Zlight2 Reference Design
- Evaluation Kits: CC2530 Evaluation Module Kit
- Evaluation Kits: MSP430F5529 USB LaunchPad Evaluation Kit
- Evaluation Kits: CC2530-CC2591EM Reference Design
- Evaluation Kits: CC2530-CC2591 Evaluation Module Kit
- Evaluation Kits: RF6505-CC2530 Reference Design
- Evaluation Kits: ZLL Remote Control Reference Design
- Evaluation Kits: CC Antenna Development Kit
- Evaluation Kits: TDK Corporation balun optimized for CC253x
- Evaluation Kits: CC2530EM Reference Design
- Evaluation Kits: CC2530 with Skyworks' SE2431L range extender FEM
- Evaluation Kits: CC2530 Development Kit
- Evaluation Kits: Debugger and Programmer for RF System-on-Chips
- Evaluation Kits: CC2530 ZigBee Light Link Development Kit
- Evaluation Kits: Segment LCD-Based Low-End In-Home Display with Wireless RF Communication
- Evaluation Kits: CC2533 RF4CE Development Kit
- Evaluation Kits: Sub-1 GHz and 2.4 GHz Antenna Reference Designs
- Evaluation Kits: CC2531 USB Evaluation Module Kit
- Evaluation Kits: RemoTI Target Module and Remote Reference Design
- Evaluation Kits: CC2530 ZigBee Development Kit
- Evaluation Kits: Smart Home and Energy Gateway Reference Design
- Evaluation Kits: CC2533 Development Kit
- Evaluation Kits: CC2530EM Ref Des with optimized JTI chip balun
CC2530F128RHAT应用笔记
- AN086 -- Using CC2591 Front End with CC2530 and CC2531 (Rev. A)
- DN041 -- Using CC253X or CC254X with Dipole PCB Antenna
- AN071 -- CC2430 to CC2530 Migration Guide
- DN034 -- YAGI 2.4 GHz PCB Antenna
- DN031 -- CC-Antenna-DK Documentation and Antenna Measurements Summary
- AN107 - Murata Balun for CC253x and CC254x, LFB182G45BG2D280 (Rev. A)
- AN060 - Security on TI IEEE 802.15.4 Compliant RF Devices (Rev. A)
- DN037 -- Measurement Results for Combined CC2530 and CC2590 Solution
- AN074 -- RemoTI Coexistence Testing
- RemoTI? Capacitive Touch Sensing (Rev. A)
- DN000 - Design Note Overview (Rev. T)
- AN079 -- Measuring Power Consumption of CC2530 with Z-Stack
- AN058 -- Antenna Selection Guide (Rev. B)
- Developing a ZigBee System Using CC2530-ZNP Approach
- AN081 -- Johanson Technology Balun Optimized for CC253X, CC254X, CC257X, CC853X (Rev. B)
- CC2530 With Skyworks? SE2431L Range Extender Front End
- DN035 -- Antenna Quick Guide (Rev. A)
- CC2530 FAQ (Rev. A)
- AN111 - Using RF6505 Front End Module with CC2530 under FCC 15.247
- DN113 CC111xFx CC243xFx CC251xFx CC253xFx SPI Interface (Rev. A)
- AN078 -- TIMAC and Z-Stack Modifications for using CC2591 RF Front End with CC2
- AN103 -- Basic RF Testing of CCxxxx Devices
- AN084 - RemoTI SimpleConsole Application (Rev. C)
- AN098 - Layout Review Techniques for Low Power RF Designs (Rev. A)
- AN118 -- Flash programming of CC253x/4x devices
- DN117 -- SimpliciTI-compatible UART Driver
- DN112 -- Using UART in CC111xFx CC243x CC251xFx and CC253xFx (Rev. B)
- DN116 -- Clearing Module Interrupt Flags in LPW SoC Devices
- AN114 -- Z-Stack Duty Cycle Analysis
- AN104 -- TDK Corporation balun optimized for CC253x
- AN100 - Crystal Selection Guide (Rev. C)
