CC430F5137IRGZR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | RF Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 12 bit |
| Core： | RISC |
| Data Bus Width： | 16 bit |
| Maximum Clock Frequency： | 20 MHz |
| Program Memory Size： | 32 kB |
| Data RAM Size： | 4 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 3.6 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | VQFN-48 |
| Mounting Style： | SMD/SMT |
| Packaging： | Reel |
| A/D Channels Available： | 6 |
| Bandwidth： | 812 kHz |
| Brand： | Texas Instruments |
| Data RAM Type： | SRAM |
| Development Kit： | EM430F5137RF900 |
| Interface Type： | I2C, SPI, UART, |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 30 |
| Number of Timers： | 2 |
| Processor Series： | CC430 RF |
| Program Memory Type： | Flash |
| Series： | CC430F5137 |
| Factory Pack Quantity： | 2500 |
| Supply Voltage - Max： | 3.6 V |
| Supply Voltage - Min： | 2 V |
CC430F5137IRGZR相关文档
- Evaluation Kits: CC430F5137 Wireless Development Tool
- Evaluation Kits: MSP430 USB Debugging Interface
- Evaluation Kits: CC430 Sub-GHz RF Experimenter?s Board
- Evaluation Kits: Sub-1 GHz RF Spectrum Analyzer Tool
- Evaluation Kits: MSP-GANG Production Programmer
CC430F5137IRGZR应用笔记
- DN502 -- CRC Implementation (Rev. D)
- Design Considerations When Using the MSP430 Graphics Library
- DN022 -- CC110x CC111x OOK ASK Register Settings (Rev. E)
- DN036 -- CC1101+CC1190 600 kbps Data Rate, +19 dBm Transmit (Rev. A)
- AN058 -- Antenna Selection Guide (Rev. B)
- AN094 -- Using the CC1190 Front End with CC1101 under EN 300 220
- DN000 - Design Note Overview (Rev. T)
- AN001 -- SRD regulations for license free transceiver operation
- AN003 -- SRD Antennas
- DN023 -- 868 MHz, 915 MHz and 955 MHz Inverted F Antenna (Rev. C)
- DN035 -- Antenna Quick Guide (Rev. A)
- DN016 -- Compact Antenna Solution for 868/915 MHz (Rev. B)
- AN072 -- Using the TAI-SAW TA0801A SAW Filter and External PA (Rev. A)
- DN005 -- CC11xx Sensitivity versus Frequency Offset and Crystal Accuracy (Rev. C)
- DN033 - Mitsubishi Ceramic Antenna for 868 MHz, 915 MHz & 955 (Rev. A)
- DN507 -- FEC Decoding
- MSP430F5xx and MSP430F6xx Core Libraries (Rev. C)
- DN024 -- 868 MHz, 915 MHz and 955 MHz Monopole PCB Antenna (Rev. E)
- CC430-Based Wireless Mesh Network Mains Switch
- DN032 -- Options for Cost Optimized CC11xx Matching
- AN088 -- SimpliciTI on the CC430 ? Practical Modifications
- CC430 RF Examples (Rev. C)
- CC430 Wake-On-Radio Functionality (Rev. A)
- AN105 -- Using 1W RF3858 Front End with CC1101 Under FCC 15.247 (Rev. A)
- DN508 -- Frequency Scanning using CC430Fx, CC110x, and CC111xFx
- DN002 -- Practical Sensitivity Testing
- AN050 -- Using the CC1101 in the European 868MHz SRD band (Rev. B)
- DN019 -- Powering Low-Power RF Products (Rev. B)
- Using a DC-DC Converter to Reduce Power (Current) Consumption In CC430 Systems
- DN031 -- CC-Antenna-DK Documentation and Antenna Measurements Summary
- Using the USCI I2C Master
