CD74HC126EE4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Buffers & Line Drivers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Input Lines： | 4 |
| Number of Output Lines： | 4 |
| Polarity： | Non-Inverting |
| Supply Voltage - Max： | 6 V |
| Supply Voltage - Min： | 2 V |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | Through Hole |
| Package / Case： | PDIP-14 |
| Packaging： | Tube |
| High Level Output Current： | - 7.8 mA |
| Logic Family： | HC |
| Logic Type： | CMOS |
| Low Level Output Current： | 7.8 mA |
| Minimum Operating Temperature： | - 55 C |
| Number of Channels per Chip： | 4 |
| Output Type： | 3-State |
| Propagation Delay Time： | 100 ns at 2 V, 20 ns at 4.5 V, 17 ns at 6 V |
| Series： | CD74HC126 |
| Factory Pack Quantity： | 25 |
| Unit Weight： | 1 g |
CD74HC126EE4相关文档
CD74HC126EE4应用笔记
- Using High Speed CMOS and Advanced CMOS in Systems With Multiple Vcc
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- Selecting the Right Texas Instruments Signal Switch
- CMOS Power Consumption and CPD Calculation (Rev. B)
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- Input and Output Characteristics of Digital Integrated Circuits
- SN54/74HCT CMOS Logic Family Applications and Restrictions
- Live Insertion
- TI IBIS File Creation, Validation, and Distribution Processes
- Designing With Logic (Rev. C)
- Shelf-Life Evaluation of Lead-Free Component Finishes
