CD74HC4049PWR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Buffers & Line Drivers |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Input Lines： | 6 |
| Number of Output Lines： | 6 |
| Polarity： | Inverting |
| Supply Voltage - Max： | 6 V |
| Supply Voltage - Min： | 2 V |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-16 |
| Packaging： | Reel |
| High Level Output Current： | - 5.2 mA |
| Logic Family： | HC |
| Logic Type： | CMOS |
| Low Level Output Current： | 5.2 mA |
| Minimum Operating Temperature： | - 55 C |
| Number of Channels per Chip： | 5 |
| Propagation Delay Time： | 85 ns at 2 V, 17 ns at 4.5 V, 14 ns at 6 V |
| Series： | CD74HC4049 |
| Factory Pack Quantity： | 2000 |
| Unit Weight： | 62 mg |
CD74HC4049PWR相关文档
CD74HC4049PWR应用笔记
- SN54/74HCT CMOS Logic Family Applications and Restrictions
- Using High Speed CMOS and Advanced CMOS in Systems With Multiple Vcc
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- Selecting the Right Texas Instruments Signal Switch
- CMOS Power Consumption and CPD Calculation (Rev. B)
- Input and Output Characteristics of Digital Integrated Circuits
- Designing With Logic (Rev. C)
- TI IBIS File Creation, Validation, and Distribution Processes
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Live Insertion
