CD74HC4538E的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Monostable Multivibrator |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Elements per Chip： | 2 |
| Logic Family： | HC |
| Logic Type： | Monostable Multivibrator |
| Package / Case： | PDIP-16 |
| Propagation Delay Time： | 250 ns, 50 ns, 43 ns |
| High Level Output Current： | - 5.2 mA |
| Low Level Output Current： | 5.2 mA |
| Supply Voltage - Max： | 6 V |
| Supply Voltage - Min： | 2 V |
| Maximum Power Dissipation： | 136 mW |
| Maximum Operating Temperature： | + 125 C |
| Minimum Operating Temperature： | - 55 C |
| Packaging： | Tube |
| Mounting Style： | Through Hole |
| Operating Supply Voltage： | 2.5 V, 3.3 V, 5 V |
| Series： | CD74HC4538 |
| Factory Pack Quantity： | 25 |
| Unit Weight： | 1 g |
CD74HC4538E应用笔记
- SN54/74HCT CMOS Logic Family Applications and Restrictions
- Live Insertion
- TI IBIS File Creation, Validation, and Distribution Processes
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Designing With Logic (Rev. C)
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- Input and Output Characteristics of Digital Integrated Circuits
- Using High Speed CMOS and Advanced CMOS in Systems With Multiple Vcc
- Selecting the Right Texas Instruments Signal Switch
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- CMOS Power Consumption and CPD Calculation (Rev. B)
