CD74HCT14M96的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Inverters |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Circuits： | 6 |
| Logic Family： | HCT |
| Logic Type： | CMOS |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 4.5 V |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOIC-14 |
| Packaging： | Reel |
| High Level Output Current： | - 4 mA |
| Input Level： | CMOS |
| Low Level Output Current： | 4 mA |
| Minimum Operating Temperature： | - 55 C |
| Operating Temperature Range： | - 55 C to + 125 C |
| Output Level： | TTL |
| Propagation Delay Time： | 135 ns |
| Series： | CD74HCT14 |
| Factory Pack Quantity： | 2500 |
| Unit Weight： | 129.400 mg |
CD74HCT14M96应用笔记
- TI IBIS File Creation, Validation, and Distribution Processes
- Designing With Logic (Rev. C)
- Understanding Schmitt Triggers
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- Using High Speed CMOS and Advanced CMOS in Systems With Multiple Vcc
- CMOS Power Consumption and CPD Calculation (Rev. B)
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
