CSD16415Q5的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | MOSFET |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 25 V |
| Vgs - Gate-Source Breakdown Voltage： | - 12 V to + 16 V |
| Id - Continuous Drain Current： | 38 A |
| Rds On - Drain-Source Resistance： | 990 mOhms |
| Configuration： | Single Quad Drain Triple Source |
| Qg - Gate Charge： | 21 nC |
| Maximum Operating Temperature： | + 150 C |
| Pd - Power Dissipation： | 3.2 W |
| Mounting Style： | SMD/SMT |
| Package / Case： | VSON-8 Clip |
| Packaging： | Reel |
| Fall Time： | 12.7 ns |
| Forward Transconductance - Min： | 168 S |
| Minimum Operating Temperature： | - 55 C |
| Rise Time： | 30 ns |
| Series： | CSD16415Q5 |
| Factory Pack Quantity： | 2500 |
| Tradename： | NexFET |
| Typical Turn-Off Delay Time： | 20 ns |
CSD16415Q5相关文档
- PCN: Qualification of Amkor Philippines as Alternate Assembly/Test site for select PQFN Devices
- Evaluation Kits: Power Solution for an Automotive Voltage Stabilizer
- Evaluation Kits: Power Solution for an Automotive Voltage Quality Module
- Function Diagram: alt_slps259
- PCN: Qualification of Reduced Wire Bond diameter for the Family of Discrete Clip & Power Block Devices
