CY8C4014LQI-422的详细信息
Manufacturer: | Cypress Semiconductor |
---|---|
Product Category: | ARM Microcontrollers - MCU |
RoHS: | Yes |
Core: | ARM Cortex M0 |
Data Bus Width: | 32 bit |
Maximum Clock Frequency: | 16 MHz |
Program Memory Size: | 16 kB |
Data RAM Size: | 2 kB |
On-Chip ADC: | No |
Operating Supply Voltage: | 1.71 V to 5.5 V |
Maximum Operating Temperature: | + 85 C |
Package / Case: | QFN-24 |
Mounting Style: | SMD/SMT |
Brand: | Cypress Semiconductor |
Data RAM Type: | SRAM |
Interface Type: | I2C |
Minimum Operating Temperature: | - 40 C |
Number of Programmable I/Os: | 5 |
Number of Timers: | 1 |
On-Chip DAC: | Yes |
Packaging: | Tray |
Processor Series: | CY8C4014 |
Program Memory Type: | Flash |
Series: | PSoC4000 |
Tradename: | PSoC |
PSoC® 4: PSoC 4000 Family
Datasheet
®
Programmable System-on-Chip (PSoC )
General Description
®
PSoC 4 is a scalable and reconfigurable platform architecture for a family of programmable embedded system controllers with an
®
ARM Cortex™-M0 CPU. It combines programmable and reconfigurable analog and digital blocks with flexible automatic routing. The
PSoC 4000 product family is the smallest member of the PSoC 4 platform architecture. It is a combination of a microcontroller with
standard communication and timing peripherals, a capacitive touch-sensing system (CapSense) with best-in-class performance, and
general-purpose analog. PSoC 4000 products will be fully upward compatible with members of the PSoC 4 platform for new applica-
tions and design needs.
Features
32-bit MCU Subsystem
Timing and Pulse-Width Modulation
■ 16-MHz ARM Cortex-M0 CPU
■ Up to 16 KB of flash with Read Accelerator
■ Up to 2 KB of SRAM
■ One 16-bit Timer/Counter/Pulse-Width Modulator (TCPWM)
block
■ Center-aligned, Edge, and Pseudo-Random modes
■ Comparator-based triggering of Kill signals for motor drive and
other high-reliability digital logic applications
Programmable Analog
■ Two current DACs (IDACs) for general-purpose or capacitive
sensing applications
Up to 20 Programmable GPIO Pins
■ One low-power comparator with internal reference
■ 24-pin QFN, 16-pin SOIC, 16-pin QFN, and 8-pin SOIC
packages
Low Power 1.71-V to 5.5-V operation
■ GPIO pins on Ports 0, 1, and 2 can be CapSense or have other
functions
2
■ Deep Sleep mode with wake-up on interrupt and I C address
detect
■ Drive modes, strengths, and slew rates are programmable
Capacitive Sensing
PSoC Creator Design Environment
■ Cypress Capacitive Sigma-Delta (CSD) provides best-in-class
signal-to-noise ratio (SNR) and water tolerance
■ Integrated Development Environment (IDE) provides
schematic design entry and build (with analog and digital
automatic routing)
■ Cypress-supplied software component makes capacitive
sensing design easy
■ Applications Programming Interface (API) component for all
fixed-function and programmable peripherals
■ Automatic hardware tuning (SmartSense™)
Serial Communication
Industry-Standard Tool Compatibility
2
■ Multi-master I C block with the ability to do address matching
■ After schematic entry, development can be done with
ARM-based industry-standard development tools
during Deep Sleep and generate a wake-up on match
Cypress Semiconductor Corporation
Document Number: 001-89638 Rev. *B
•
198 Champion Court
•
San Jose, CA 95134-1709
•
408-943-2600
Revised May 16, 2014
