DAMZ-3W3S-N-A197的详细信息
| Datasheets： | |
|---|---|
| DAMZ3W3SNA197： | |
| Standard Package ： | 1 |
| Category： | Connectors, Interconnects |
| Family： | D-Sub, D-Shaped Connectors - Housings |
| Series： | Combo D®, D*M |
| Packaging ： | Bulk |
| Connector Style： | D-Sub, Combo |
| Connector Type： | Receptacle for Female Contacts |
| Number of Positions： | 3 (Coax or Power) |
| Number of Rows： | 1 |
| Shell Size, Connector Layout： | 2 (DA, A) - 3W3 |
| Contact Type： | Coax or Power |
| Mounting Type： | Panel Mount |
| Flange Feature： | Board Side (4-40) |
| Features： | Board Lock, Shielded |
| Shell Material, Finish： | Steel, Tin Plated |
| Shell Finish Thickness： | - |
| Note： | Contacts Not Provided |
| Ingress Protection： | - |
| Operating Temperature： | -55°C ~ 125°C |
| Mating Cycles： | - |
| Dielectric Material： | Polyester |
| Color： | Black |
| Mating Products： | IDAM3W3PF225-ND - DSUB 3W3 M SOD SS SHL F225IDAM3W3PA101-ND - DSUB 3W3 M CADDAMY-3W3P-K87-ND - CONN DSUB PLUG 3W3 HSGDAM-3W3P-K127-ND - CONN DSUB PLUG 3W3 HSGIDAM3W3PJK87-ND - DSUB 3W3 M PCR/A TIDAM3W3PNK87-ND - DSUB 3W3 M PCB G TIDAM3W3PA191-ND - DSUB 3W3 M SOD G30IDAM3W3P-ND - DSUB 3W3 MIDAM3W3PA176-ND - DSUB 3W3 M SOD G30 0 |
| Other Names： | 053512-3019535123019DAMZ3W3SNA197IDAMZ3W3SNA197IDAMZ3W3SNA197-ND |
